190HP Sc7h220ca2 Sdec Chinese Marine Fish Boat Ship Diesel Engine with Shaft Propeller
Product DescriptionProduct Description 190HP SC7H220CA2 SDEC Chinese Marine Fish Boat Ship Diesel Engine with shaft propellerEngine Specifications:Engine ModelSC7H250CA2MakerShangHai diesel engine Co.,LtdRated power167kwRated speed 2300rpmEngine TypeInlin......
Send Inquiry
Product Description
Product Description
190HP SC7H220CA2 SDEC Chinese Marine Fish Boat Ship Diesel Engine with shaft propeller
Engine Specifications:
Engine Model | SC7H250CA2 |
Maker | ShangHai diesel engine Co.,Ltd |
Rated power | 167kw |
Rated speed | 2300rpm |
Engine Type | Inline-6 Cylinders,4-stroke Diesel engine |
Bore x Stroke | 105mm x 124mm |
Combustion system | Direct Injection |
Aspiration | Turbocharged & Intercooled |
Cylinder Number | 6 |
Cooling System | Heat Exchanger |
Displacement | 6.44L |
Rotation | Anti-clockwise (facing Flywheel) |
Size of Flywheel Housing &Flywheel | SAE3#11 1/2 in |
Certification&Emissions | CCS+IMO Tier II |
Dry Weight | 675kg |
Dimension(L x W x H) | 1266 x 729 x 1179mm |
Series Model:
Engine Model | Rated Power/Speed (kw/r/min) | Overload Power/Speed (kw/r/min) | UNA Rated power/speed(kw/r/min) | UNA Overload Power/Speed (kw/r/min) |
SC7H175CA2 | 115kw/1500rpm | 127kw/1545rpm | 112kw/1500rpm | 123kw/1545rpm |
SC7H195CA2 | 129kw/1500rpm | 142kw/1545rpm | 125kw/1500rpm | 138kw/1545rpm |
SC7H190CA2 | 125kw/1800rpm | 137kw/1854rpm | 121kw/1800rpm | 133kw/1854rpm |
SC7H220CA2 | 144kw/1800rpm | 159kw/1854rpm | 140kw/1800rpm | 154kw/1854rpm |
SC7H235CA2 | 155kw/2100rpm | 170kw/2163rpm | 150kw/2100rpm | 165kw/2163rpm |
SC7H250CA2 | 167kw/2300rpm | 184kw/2369rpm | 162kw/2300rpm | 178kw/2369rpm |
SC7H230CF2 | 154kw/1500rpm | 170kw/1500rpm | 149kw/1500rpm | 164kw/1500rpm |
SC7H250CF2 | 168kw/1500rpm | 185kw/1500rpm | 163kw/1500rpm | 179kw/1500rpm |
Marine Gear Specification:
Gear Model | 120C | HC138 |
Type | Hydraulic multi-disc clutch | |
Reduction Ratio | 1.94,2.45 | 2.00,3.00,3.57,4.05,4.45 |
Direction of Rotation | Clockwise or anti-clockwise from stern | |
Dry weight | 225kg | 360kg |
Dimension(L x W x H) | 432 x 440 x 650mm | 520x 792x 760mm |
Mechanical Efficiency | 97% | |
